GIGABYTE MU72-SU0 ATX Server Motherboard
$684.48
GIGABYTE MU72-SU0 ATX Server Motherboard Socket P+ Intel C621A
| Best Seller Ranking |
#83 in Server Motherboards |
|---|---|
| Brand |
GIGABYTE |
| Model |
MU72-SU0 |
| CPU Socket Type |
Socket P+ |
| CPU Type |
Supports 3rd Gen Intel Xeon Scalable ProcessorsSupports Intel Xeon Platinum ,Xeon Gold ,Xeon Silver Processors |
| North Bridge |
Intel C621A |
| Number of DDR4 Slots |
8 x 288-pin |
| DDR4 Standard |
DDR4 3200 |
| Maximum Memory Supported |
256GB |
| PCI Express 4.0 x16 |
Slot_7: 1 x PCIe x16 (Gen4 x16 bus) slotSlot_6: 1 x PCIe x16 (Gen4 x16 or x8 bus) slot ,shared with Slot_5Slot_5: 1 x PCIe x16 (Gen4 x0 or x8 bus) slotSlot_4: 1 x PCIe x16 (Gen4 x16 or x8 bus) slot ,shared with Slot_3Slot_3: 1 x PCIe x16 (Gen4 x0 or x8 bus) slotSlot_2: 1 x PCIe x16 (Gen4 x16 or x8 bus) slot ,shared with Slot_1Slot_1: 1 x PCIe x16 (Gen4 x0 or x8 bus) slot |
| SATA RAID |
0/1/10/5 |
| SAS |
3 x SlimSAS for 12 x SATA III 6Gb/s ports |
| M.2 |
1 x M.2 slot:- M-key- PCIe Gen3 x4 per slot- Supports NGFF-2280 cards |
| Onboard Video Chipset |
Aspeed AST2600 |
| LAN Chipset |
Intel I210-AT |
| LAN Speed |
10/100/1000Mbps |
| Max LAN Speed |
1Gbps |
| Back I/O Ports |
4 x USB 3.01 x VGA1 x COM2 x RJ451 x MLAN1 x ID button with LED |
| Other Connectors |
1 x 24-pin ATX main power connector1 x 8-pin ATX 12V power connector1 x 6-pin ATX 12V power connector ( for PCIe slot)3 x SlimSAS connectors1 x M.2 slot1 x CPU fan header6 x System fan headers1 x USB 3.0 header1 x TPM header1 x VROC connector1 x Front panel header1 x Buzzer |
| Form Factor |
ATX |
| Dimensions W x L |
12" x 10" |
| Package Contents |
1 x MU72-SU01 x I/O shield1 x Quick start guide1 x SlimSAS for 4 x SATAIII 6Gb/s cable |
| First Listed on Newegg |
January 10 ,2022 |
